JAE MX34 Series Connector Cable

Views : 197
Update time : 2025-05-07 20:12:00
The JAE MX34 Series connector cable is a high-performance cable assembly designed to use connectors from the JAE MX34 Series, which are compact, reliable connectors primarily used in automotive applications. These connectors are known for their durability, resistance to vibration, and secure mating features, making them a popular choice in harsh environments.


JAE MX34 Series Connector Overview

Connector Family: MX34
Application: Automotive and other industries requiring compact, reliable connections.
Number of Positions: Available in multiple pin counts (e.g., 16, 20, 32 pins) for various applications.
Pitch: Typically 2.2 mm.
Current Rating: Up to 3 A per pin.
Voltage Rating: Up to 250 V AC/DC.
Temperature Range: -40°C to +105°C.
Material:
Housing: High-temperature resistant plastic.
Contacts: Copper alloy with tin or gold plating for enhanced conductivity and corrosion resistance.

Key Features of the MX34 Series

Compact Design:
Ideal for applications where space is a constraint.
Vibration Resistance:
Secure locking mechanism prevents accidental disconnection in high-vibration environments.
Sealed and Unsealed Options:
Sealed versions for waterproof applications (IP67 rated).
Unsealed versions for standard connections in controlled environments.
High Density:
Supports a large number of pins in a small form factor, allowing efficient wiring.
Secure Connection:
Features a dual-locking system for enhanced reliability.

Applications

Automotive:
Engine control units (ECUs).
Body control modules (BCMs).
Lighting systems.
Airbags and safety systems.
Industrial Equipment:
Control systems requiring robust connections.
Consumer Electronics:
Devices exposed to vibration or harsh conditions.

Features of JAE MX34 Series Connector Cable Assembly

Connector Type:
The cable uses connectors from the MX34 series, either at one or both ends.
Cable Configuration:
Available in various pin configurations based on the specific MX34 connector used.
Can accommodate signal and low-power connections.
Wire Gauge:
Compatible with wire sizes ranging from 22 AWG to 28 AWG, depending on application.
Cable Length:
Customizable to suit installation needs.
Shielding:
Shielded options are available to protect against electromagnetic interference (EMI) in sensitive environments.
Environmental Protection:
Sealed versions provide resistance to water, dust, and other contaminants, meeting IP67 standards.
Customization:
Overmolding for added durability and strain relief.
Color-coded wires for easy identification.

Advantages of JAE MX34 Series Connector Cables

Reliability: Secure connection in demanding environments.
Flexibility: Suitable for high-density connections in tight spaces.
Durability: Withstands high temperatures, vibrations, and moisture.
Customizable: Tailored lengths, pin configurations, and shielding options.

Customization Options

A custom JAE MX34 Series connector cable can include:
Specific pinouts to match the application requirements.
Cable materials for resistance to heat, oil, or chemicals.
Enhanced strain relief and overmolding.
Wire terminations (e.g., crimped, soldered).
Shielded or unshielded versions.

Summary

The JAE MX34 Series connector cable is a robust, compact, and highly reliable solution for automotive and industrial applications. With options for sealing, vibration resistance, and high-density pin configurations, it ensures long-lasting performance in harsh conditions. Customizable assemblies can be designed to meet specific electrical and environmental requirements.
